LED Sports Light
SF13 Series
Product Introduction
-
Modular High-Power Design
The SF13 Series LED sports light features a modular structure with system power configurations from 240W up to 1250W. Each module supports power adjustable settings (250W / 200W / 150W), allowing flexible configuration for different lighting heights and project requirements.
-
High-Efficiency LED Performance
Equipped with Lumileds 2835 and OSRAM 3737 LED chips, the fixture delivers 150–170 lm/W luminous efficacy, providing powerful and energy-efficient illumination for large-area outdoor lighting.
-
Multiple Professional Beam Angles
The SF13 Series offers 10°, 15°, 25°, 45°, 60°, and 90° beam angles, as well as asymmetrical 65°×25° optics, enabling precise light distribution for sports and high mast lighting applications.
-
Durable Outdoor Construction
Built with ADC12 die-cast aluminum housing and polycarbonate lenses, the luminaire provides strong durability and heat dissipation. With IP66 protection and IK08 impact resistance, it is designed for reliable operation in demanding outdoor environments.
-
Suitable for Professional Sports & Large Venues
The SF13 Series is suitable for soccer fields, athletic fields, basketball courts, baseball fields, hockey fields, tennis courts, badminton courts, stadium arenas, exhibition centers, and airports, where high-power and wide-area lighting is required.
Specification
|
Product |
Code |
Dimension |
CCT |
Power |
Voltage |
|
SF13 Series |
4CSF13-A-250W |
558*293*93mm |
3000K~6500K |
240W-200W-150W ADJ |
AC100~277V,50-60Hz |
|
SF13 Series |
4CSF13-A-500W |
558*457*93mm |
3000K~6500K |
480W-400W-300W ADJ |
AC100~277V,50-60Hz |
|
SF13 Series |
4CSF13-A-750W |
558*621*93mm |
3000K~6500K |
720W-600W-400W ADJ |
AC100~277V,50-60Hz |
|
SF13 Series |
4CSF13-A-1000W |
558*784*93mm |
3000K~6500K |
960W-800W-600W ADJ |
AC100~277V,50-60Hz |
|
SF13 Series |
4CSF13-A-1250W |
558*948*93mm |
3000K~6500K |
1200W-1000W-600W ADJ |
AC100~277V,50-60Hz |
